Brushless DC motor with high power to weight and size ratio
Features:
- Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
- Max. 3-3/4” cut capacity (at 0°) ideal for single pass cutting of 4X dimensional lumber
- eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
- Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
- Soft start feature gradually increases speed to eliminate start up shock
- Trigger-lock button prevents accidental start-up for increased safety
- Bevel capacity of 0° – 56° with positive stop at 22.5° and 45°
- High performance and lightweight design with magnesium blade case and base plate
Specifications:
- Battery Capacities –40V Max Li-Ion
- Blade Diameter –10-1/4″ (260 mm)
- Arbor –5/8″ (15.88 mm)
- Maximum Cutting Depth:
- 0° –3-3/4″ (95 mm)
- 45° –2-3/4″ (70 mm)
- 56°–2-1/8″ (54.5 mm)
- No Load Speed –4,000 RPM
- Vibration Level –2.5 m/s²
- Noise Level –96 dB(A)
- Overall Length –19-1/4″ (486 mm)
- Net Weight –11.1 lbs (4.99 kg)
