Brushless DC motor with high power to weight and size ratio
Features:
- Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
- Max. 2-9/16” cut capacity (at 0°) ideal for single pass cutting of 3X dimensional lumber
- Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition, enabling rapid movement between high speed and high torque applications
- eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
- Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
- Soft start feature gradually increases speed to eliminate start up shock
- Trigger-lock button prevents accidental start-up for increased safety
- Bevel capacity of 0° – 53° with positive stop at 22.5° and 45°
Specifications:
- Battery Capacities –40V Max Li-Ion
- Blade Diameter –7-1/4″ (185 mm)
- Arbor –5/8″ (15.88 mm)
- Maximum Cutting Depth:
- 0° –2-9/16″ (65 mm)
- 45° –1-3/4″ (45 mm)
- 53° –1-1/2″ (38 mm)
- No Load Speed –6,400 RPM
- Vibration Level –2.5 m/s²
- Noise Level –92 dB(A)
- Overall Length –17-1/2″ (446 mm)
- Net Weight –9.6 lbs (4.3 kg)
