Linear Bearing Slide Mechanism allows extremely smooth plunge action
Features:
- Larger Ball Bearings on Armature enhance durability of tool
- Labyrinth Retainers and Fan prevent contamination of motor
- Plunge Depth can be adjusted from the bottom of the router when mounted in a router table
- Trigger Switch with Lock-On/Off Button located on handle for operator convenience
- 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
- Four Raised Ribs on top of Motor Housing provide a stable platform during bit changes
- Dual LED Job Lights with Afterglow
- Sub-Base accepts industry standard template guides
Specifications:
- Collet Capacity — 1/2″ (12.7 mm)
- Plunge Capacity — 2-3/4″ (70 mm)
- No Load Speed — 22,000 RPM
- AMPS (120V) — 15.0 A
- Vibration Level — 4.0 m/s²
- Noise Level — 86 dB(A)
- Base Diameter –6-11/16″ (170 mm)
- Overall Height — 12-1/4″ (312 mm)
- Net Weight — 13.2 lbs (6.0 kg)
