Rail forward design enables saw to be placed against wall to maximize effective workspace
Features:
- 3 stage gear reduction system greatly increases capacity when cutting vertical baseboard or nested crown molding
- 1-3/16″ guide rail diameter provides increased stability and cutting precision
- Integrated guide fence and lower fence increases rigidity and support of materials
- Fence design allows fence to be secured to holders to prevent damage and/or loss
- Front bevel knob enables easy adjustment without reaching for operator convenience and precise setting of bevel angle
- Electronic speed control maintains constant speed under heavy load
- Soft start feature gradually increases speed to eliminate start up shock
- Bevel capacity of 48° left or right with positive stops at 0°, 22.5°, 33.9°, 45° & 48°
Specifications:
- Blade Diameter –10″ (255 mm)
- Arbor –5/8″ (15.88 mm)
- No Load Speed –3,200 RPM
- AMPS (120V) –15.0 A
- Vibration Level –2.5 m/s²
- Noise Level –91 dB(A)
- Dimensions (L x W x H) — 31-3/4″ x 25″ x 26″ (805 mm x 644 mm x 660 mm)
- Net Weight –57.6 lbs (26.1 kg)
